I joined Datadog in January 2024, and in February, my colleague Ara Pulido connected me with Mastodon to help onboard their backend to Datadog.

Mastodon had been using Datadog for a year through Datadog’s Open Source Program, primarily to monitor their hosts, Kubernetes cluster, logs, and database performance. However, they were exploring OpenTelemetry to get vendor agnostic instrumentation into their backend.

I wrote about this on Datadog’s Open Source Hub, but I wanted to share some personal and technical insights that didn’t quite fit in that post—so here we go.

Initial Challenges
#

When I started examining the source code, I discovered that Mastodon is written in Ruby. Although I had previously worked with Ruby, creating a sample Ruby app is quite different from working on a real-world application. Fortunately, it worked out well.

The community had already begun developing something similar. In November 2022, Robb Kidd submitted a pull request to add OpenTelemetry (OTel) to Mastodon, and I built a solution on top of that by integrating the OTel Collector.

The PR with the Collector
#

Even though this wasn’t the pull request that ultimately got merged, I’d like to take a moment to discuss a suggestion I made.

The Collector
#

Since Mastodon wanted to enable users to send telemetry data to any observability backend, I aimed to allow developers to configure their own Collector as needed, but creating a minimal custom Collector containing only the required components for each use-case.

To achieve this, I used a multi-stage Dockerfile. First, it uses the OpenTelemetry Collector Builder (OCB) to create a minimal Collector distribution based on a manifest file specifying which components should be included. It then runs the Collector with its configuration file.

Here’s an example of what a manifest.yaml file looks like:

dist:
  module: github.com/mastodon/mastodon/dist/opentelemetry-collector
  name: otelcol
  description: Custom OpenTelemetry Collector
  version: 0.113.0
  output_path: ./_build

receivers:
  - gomod: go.opentelemetry.io/collector/receiver/otlpreceiver v0.113.0

exporters:
  - gomod: go.opentelemetry.io/collector/exporter/debugexporter v0.113.0
  - gomod: go.opentelemetry.io/collector/exporter/otlpexporter v0.113.0
  - gomod: go.opentelemetry.io/collector/exporter/otlphttpexporter v0.113.0

processors:
  - gomod: go.opentelemetry.io/collector/processor/batchprocessor v0.113.0
  - gomod: go.opentelemetry.io/collector/processor/memorylimiterprocessor v0.113.0
  - gomod: github.com/open-telemetry/opentelemetry-collector-contrib/processor/resourcedetectionprocessor v0.113.0
  - gomod: github.com/open-telemetry/opentelemetry-collector-contrib/processor/resourceprocessor v0.113.0

Below is an example of the Dockerfile:

FROM golang:latest as build

ARG TARGETARCH

ARG BUILDER_VERSION=0.113.0

RUN curl --proto '=https' --tlsv1.2 -fL -o bin/ocb \
    https://github.com/open-telemetry/opentelemetry-collector-releases/releases/download/cmd%2Fbuilder%2Fv${BUILDER_VERSION}/ocb_${BUILDER_VERSION}_linux_${TARGETARCH}
RUN chmod +x bin/ocb
WORKDIR /build

# Copy the manifest file and builds the Collector binary
# with the defined components
COPY ./manifest.yaml ./manifest.yaml
ENV GOARCH=$TARGETARCH
ENV CGO_ENABLED=0
RUN ocb --config ./manifest.yaml --output-path /build/_build

FROM alpine:3.20 as certs
RUN apk --update add ca-certificates

# Final step runs the custom Collector binary
# with its configuration file
FROM alpine:3.20

ARG USER_UID=10001
USER ${USER_UID}

COPY --from=certs /etc/ssl/certs/ca-certificates.crt /etc/ssl/certs/ca-certificates.crt
COPY --from=build --chmod=755 /build/_build/otelcol /otelcol
COPY ./otelcol-config.yaml /etc/otelcol-config.yaml
ENTRYPOINT ["/otelcol", "--config=/etc/otelcol-config.yaml"]
EXPOSE 4317 4318

And finally, here’s an example of the otelcol-config.yaml file:

receivers:
  otlp:
    protocols:
      grpc:
        endpoint: 0.0.0.0:4317
      http:
        endpoint: 0.0.0.0:4318
        cors:
          allowed_origins:
            - 'http://*'
            - 'https://*'

processors:
  batch:
    send_batch_max_size: 1000
    send_batch_size: 100
    timeout: 10s
  memory_limiter:
    check_interval: 1s
    limit_mib: 4000
    spike_limit_mib: 800
  resourcedetection:
    detectors: [system]
    system:
      resource_attributes:
        os.description:
          enabled: true
        host.arch:
          enabled: true
        host.cpu.vendor.id:
          enabled: true
        host.cpu.family:
          enabled: true
        host.cpu.model.id:
          enabled: true
        host.cpu.model.name:
          enabled: true
        host.cpu.stepping:
          enabled: true
        host.cpu.cache.l2.size:
          enabled: true
  resource:
    attributes:
      - key: deployment.environment.name
        value: 'otel'
        action: upsert

exporters:
  debug:
    verbosity: detailed
  otlp:
    endpoint: <grpc_backend>:4317

service:
  pipelines:
    metrics:
      receivers: [otlp]
      processors: [batch, resourcedetection, resource, memory_limiter]
      exporters: [debug, otlp]
    traces:
      receivers: [otlp]
      processors: [batch, resourcedetection, resource, memory_limiter]
      exporters: [debug, otlp]
    logs:
      receivers: [otlp]
      processors: [batch, resourcedetection, resource, memory_limiter]
      exporters: [debug, otlp]
Note that you can only use the components previously added to the manifest file, as the custom Collector includes only those components. If you try to use a component not defined in the manifest, the Collector will fail to start.

In the pull request, I also added a TELEMETRY_BACKEND build argument, which selects a different manifest file depending on the observability backend the user wants to send data to. For example, the Datadog manifest includes the Datadog-specific components, while the default manifest includes only the OTLP and vendor-agnostic components.

This setup was designed to allow users to contribute their own manifests with additional components as needed.

To learn more about the OCB, refer to the official OpenTelemetry documentation: Building a custom collector.

The Instrumentation
#

The main difference between Robb’s initial PR and mine, on the instrumentation side, was that instead of using opentelemetry-instrumentation-all, I suggested adding only the specific dependencies we needed.

This approach is more verbose and requires additional maintenance, but it gives us greater control over what we’re instrumenting. It also aligns with the goal of building a minimal Collector distribution.

Rather than importing everything automatically, we define exactly what we want, use only what we need, and keep the setup streamlined.

The Collector Configuration
#

After the Mastodon team’s PR was merged, they began sending OpenTelemetry traces to Datadog via the Collector.

This sparked an invaluable back-and-forth exchange between Renaud Chaput, Tim Campbell, and me, for which I’ll be forever grateful.

As a representative of the community, users, and customers within Datadog, understanding their pain points and challenges with sending OTel data to Datadog is one of the most important aspects of my role.

In the Datadog Open Source Hub blog post, I discussed how Inferred Services significantly improved Mastodon’s usability. Here, I want to focus on specific Collector configurations that helped them navigate the OTel ecosystem within Datadog more effectively.

Resource Processor
#

In the snippet below, the resourceprocessor component is used to set an attribute: deployment.environment.name=development.

When OTel data arrives in Datadog with this attribute, the service is tagged accordingly, making it easier for the team to navigate and analyze their data in Datadog.

processors:
  [...]
  resource:
    attributes:
      - key: deployment.environment.name
        value: "development"
        action: upsert

Transform Processor
#

Working with the transformprocessor was a valuable learning experience for me. Although I was aware of the component, I had never used it myself.

Mastodon wanted assistance in improving the naming of their spans beyond the default Ruby instrumentation name.

They would like the values from code.namespace and code.function combined. If you’re unfamiliar with these terms, as I initially was, here’s an example:

A namespace might look like Api::V1::Timelines::PublicController, while the function could be show.

The snippet below demonstrates how these two values are concatenated with a # in between, resulting in Api::V1::Timelines::PublicController#show.

processors:
  [...]
  transform:
    error_mode: ignore
    trace_statements:
      - context: span
        conditions:
          - attributes["code.namespace"] != nil
        statements:
          - set(attributes["resource.name"], Concat([attributes["code.namespace"], attributes["code.function"]], "#"))
Note that we are not actually changing the span name but rather setting the resource name. This is a Datadog-specific concept that we won’t explore here, but if you’re interested, you can learn more in the Resources glossary.

Tail Sampling Processor
#

I vividly remember Reese Lee’s presentation on Tail-Based Sampling at KubeCon EU 2022. It was my first introduction to the concept, and I was truly impressed by its potential. Reese delivered a fantastic talk with a great hands-on demo.

Another noteworthy talk was from Vijay and Aishwarya from eBay at this year’s (2024) Observability Day EU. They shared that they sample only 1% of their traces, which, due to their high traffic volume, is sufficient 🤯.

Tail sampling has a challenge when using multiple Collectors: you must ensure that all spans from a trace reach the same Collector, or else you’ll end up with broken traces.

In Mastodon’s case, I was fortunate—they’re using a single Collector instance, which made configuring it much easier.

Initially, I suggested sampling 25% of traces, plus all errors, but Tim found that 10%, plus errors, met their needs.

Below is the tail_sampling processor definition for this setup.

processors:
  [...]
  tail_sampling:
    policies:
      [
        {
          name: errors-policy,
          type: status_code,
          status_code: {status_codes: [ERROR]}
        },
        {
          name: randomized-policy,
          type: probabilistic,
          probabilistic: {sampling_percentage: 10}
        },
      ]

Another important point about tail sampling is that if you’re calculating metrics from spans using components like spanmetricsconnector or datadogconnector, you need to ensure metrics are calculated before sampling.

Let me explain.

Imagine your service emits 100 traces, and you have tail sampling configured at 25%. This means your Collector will receive all 100 traces but will send approximately 25 to the observability backend.

If metrics are calculated in the same pipeline where data is exported, they’ll reflect only about a quarter of the total traces, resulting in significant information loss about your service.

To address this, you need to set up three pipelines:

  • The first pipeline receives all spans from the traces and calculates its metrics.
  • The second pipeline also receives all spans, but it samples the traces and exports only the sampled traces to the backend.
  • The third pipeline receives the calculated metrics and exports them.

Here’s an example setup:

service:
  pipelines:
    traces/all:
      receivers: [otlp]
      exporters: [spanmetrics]
    traces/sample:
      receivers: [otlp]
      processors: [tail_sampling, resource, transform, batch]
      exporters: [debug, otlp]
    metrics:
      receivers: [otlp, spanmetrics]
      processors: [resource, transform, batch]
      exporters: [debug, otlp]

It Keeps Going
#

This is a live, ongoing collaboration. Currently, I have a few open discussions with the Mastodon team, and with each iteration, I learn more, and we work together to achieve a better observability state.

I hope this collaboration continues, as learning and growth are what truly motivate me.

To wrap up, I’d like to take this opportunity to thank Ara for this amazing onboarding experience, as well as Renaud and Tim for all the back-and-forth discussions and the valuable insights I’ve gained from their use cases and questions.
